TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------
Engine
Type Air-cooled, 4-stroke single cylinder OHC
Displacement 149.1 cc
Max. Power 10 KW (13.4 BHP) @ 8000 RPM
Max. Torque 12.80 N-m @ 5000 RPM
Bore x Stroke 57.3 x 57.8 mm
Carburettor CV Type
Compression Ratio 9.1 : 1
Starting Self start / Kick start
Ingnition AMI - Advanced Microprocessor Ignition System
Transmission & Chassis
Cluch CV Type
Gear box 5 Speed constant mesh, heal & toe shift
Chassis Type Tubular, diamond type
Suspension
Front Telescopic hydraulic shock absorbers
Rear Rectangular swing arm with adjustable hydraulic shock absorber
Brakes
Front Brake Dia 240 mm Disc, Pad - Non asbestos type
Rear Brake Disc Internal expanding shoe type (130 mm) Non asbestos type
Rear Brake Drum Internal expanding shoe type (130 mm) : Liners - Non
asbestos type
Wheels & Tyres
Rim Size Front 18 x 1.60, Alloy wheel
Rim Size Rear 18 x 1.60, Alloy wheel
Tyre Size Front 2.75 x 18 - 4 PR / 42 P
Tyre Size Rear 3.00 x 18 - 6 P / 52 PR (Puncture resistant tuff - up tube)
Electricals
Battery 12V-2.5 Ah (Kick) / 7 Ah (Self)
Dimensions
Length 2040 mm
Width 760 mm
Height 1120 mm
Wheelbase 1290 mm
Ground Clearance 160 mm
Fuel Tank Capacity 12.5 Ltrs (Min): 2.3 Ltrs. (Usable reserve)
Kerb Weight 134 Kg (Kick) / 138kg (Self)
Features
>5-Spoke, black alloy wheels.
>Best mileage in 150cc category.
>ATFT 150cc Engine for the perfect balance of high power and fuel economy.
>Specially designed seat for the great riding experience.
>Puncture resistant tuff-up tube
