TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------
Engine
Type Air cooled, 4 - stroke single cylinder OHC
Displacement 97.2 cc
Max. Power 5.74 kW (7.8 Ps) at 7500 rpm
Max. Torque 0.82 Kg-m (8.04 N-m) @4500 rpm
Bore x Stroke 50.0 x 49.5 mm
Compression Ratio 9.0: 1
Starting Kick start / Self start
Ingnition DC digital CDI
Transmission & Chassis
Cluch Multi-plate wet
Gear box 4 Speed constant mesh
Chassis Type Tubular double cradle frame
Suspension
Front Telescopic hydraulic shock absorbers
Rear Swing arm with 2 step adjustable hydraulic shockabsorber
Brakes
Front Brake Internal expanding shoe type ( 130 mm )
Rear Brake Disc Internal expanding shoe type ( 110 mm )
Wheels & Tyres
Rim Size Front 18 x 1.6 Spoke wheels / Cast wheels
Rim Size Rear 18 x 1.6 Spoke wheels / Cast wheels
Tyre Size Front 2.75 x18 - 4PR/42 P
Tyre Size Rear 2.75 x 18 -6 PR/48 P
Electricals
Battery 12 V -3 Rh
Head Light 12v - 35/35W ( Halogen bulb ), Rectangular MFR
Turn Signal Lamp 12v- 10W x 4 nos - MFR
Dimensions
Length 1965 mm
Width 720 mm
Height 1045 mm
Wheelbase 1235 mm
Saddle Height 805 mm
Ground Clearance 165 mm
Fuel Tank Capacity 10.5 ltrs
Reserve 1.8 ltrs
Kerb Weight Kick/Self - 109/112 kgs
Features
> New engine for enhanced performance & stress-free ride.
> Trapezoidal multi-reflector headlight for enhanced visibility provides better safety & trendy trapezoidal shape lends more appeal to the bike.
> Broad visor with aerodynamic shape.
> Cool 3D graphics & knee grip makes the bike look very attractive & a comfortable seating posture provides a stress-free ride.
> Extra wide seat, more seating space provides better riding comfort for both driver & pillion rider.
> Adjustable rear suspension ease in adjustment of rear shockers provides riding comfort in different terrains.
> POWER START: a new era of convenience.
> Stylish 5-spoke alloy wheels for better aesthetics.
> Multi-reflector taillight higher visibility provides better safety at night.
> Introducing maintenance-free battery for the peaceful ride.
