Phoenix

TECHNICAL SPECIFICATION

--------------------------------------------------------------------------------------------------

Engine

Type Air cooled, 4 - stroke single cylinder

Displacement 149.2 c.c

Max. Power 10.6 kW (14.4 Ps) @ 8500rpm

Max. Torque 12.80 N - m @ 6500 rpm

Bore x Stroke 57.3 x 57.8 mm

Carburettor C.V Type

Compression Ratio 9.1 : 1

Starting Self Start

Ingnition AMI - Advanced Microprocessor Ignition System

Engine oil capacity 1.2 Litres

Engine oil grade SAE 10 W 30 SJ grade

Transmission & Chassis

Cluch Multiplate wet

Gear box 5 Speed constant mesh

Chassis Type Tubular, diamond type

Suspension

Front Telescopic hydraulic shock absorbers

Rear Swing arm with nitrox GRS (Gas reservoir suspension)

Brakes

Front Brake Dia 240 mm Disc

Rear Brake Disc Dia 220 mm

Rear Brake Drum Dia 130 mm

Wheels & Tyres

Rim Size Front 18 x 1.85, 5 spoke cast wheels

Rim Size Rear 18 x 2.15, 5 spoke cast wheels

Tyre Size Front 2.75 x 18 - 42 P, Tubeless tyres

Tyre Size Rear 80 / 100 X 18 - 47 P, Tubeless tyres

Electricals

Battery 12 V -4 Ah, MF battery

Head Light 12 V -35 W / 35W - Halogen bulb (Multi - reflector type)

Tail Stop Lamp 12 V -0.5 W / 4.1W LED lamp

Turn Signal Lamp 12 V -10 W (Amber bulb) x 4 nos. (Multi -

reflector clear lens)

Dimensions

Length 2080 mm

Width 765 mm

Wheelbase 1325 mm

Saddle Height 795 mm

Ground Clearance 145 mm

Fuel Tank Capacity 12.4 litres (Minimum)

Reserve 2.2 litres (Usable Reserve)

Kerb Weight 146 kgs

Minimum Turning 2.20 mtrs.
