TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------
Engine
Type Air cooled , 4 - stroke single cylinder OHC
Displacement 124.7 cc
Max. Power 8.20 kW ( 11 bhp ) @ 8000 rpm
Max. Torque 11 N-m @ 5000 rpm
Bore x Stroke 52.4 x 57.8 mm
Carburettor CV Type
Compression Ratio 9.2 :1
Starting Self Start / Kick Start
Ignition Digital CDI
Transmission & Chassis
Clutch Multiplate wet
Gear box 5 Speed constant mesh
Chassis Type Tubular , Diamond Type
Suspension
Front Telescopic Hydraulic Shock Absorbers
Rear Swing Arm with adjustable hydraulic shock absorbers
Brakes
Front Brake Dia 240 mm Disc - Non Asbestos type
Rear Brake Internal expanding shoe type ( 130 mm ) - Non Asbestos type
Wheels & Tyres
Rim Size Front 17 x 1.85, Cast Wheel
Rim Size Rear 17 x 2.15, Cast Wheel
Tyre Size Front 80/100 x 17 - M/C 46 P ( Tubeless Tyre )
Tyre Size Rear 100/90 x 17 - M/C 55P ( Tubeless Tyre )
Electricals
Battery 12 V - 3 Ah , MF Battery
Head Light 35 W / 35 W - Halogen Bulb ( Multi-Reflector )
Tail Stop Lamp 5 W / 21 W ( Multi-Reflector )
Turn Signal Lamp 10 W x 4 nos ( Multi- Reflector )
Dimensions
Length 2010 mm
Width 710 mm
Height 1095 mm
Wheelbase 1270 mm
Ground Clearance 175 mm
Kerb Weight 129 kg
