TECHNICAL SPECIFICATION
--------------------------------------------------------------------------------------------------
Engine
Type Air cooled, 4- stroke single cylinder OHC , Self start
Displacement 149.2cc
Max. Power 9.7 kW (13.2 Ps) @ 7500 rpm
Max. Torque 13.4 N-m @ 5000 rpm
Ingnition D.C - CDI Ignition System
Transmission & Chassis
Clutch Dry, Automatic Centrifugal Clutch with variomatic drive
Chassis Type High Rigidity Underbone Type
Suspension
Front Bottom Link with spring loaded hydraulic dampers
Rear Unit Swing with spring loaded hydraulic dampers
Dimensions
Wheelbase 1240 mm
Ground Clearance 155 mm
Fuel Tank Capacity 5.3 litre ( Min )
Electricals
Battery 12 V - 3 Ah , MF Battery
Head Light 12V - 35W / 35W - Halogen Bulb ( Multi-Reflector Type )
Tail Stop Lamp 12V - 5W / 21 W ( Multi-Reflector Type )
Turn Signal Lamp 12V- 10W ( Amber Bulb ) x 4 nos. ( Multi- Reflector - Clear Lens )
Brakes
Front Brake Drum; Internal expanding shoe type ( 130 mm ) (Combined Braking System)
Rear Brake Drum; Internal expanding shoe type ( 130 mm ) (Combined Braking System)
Wheels & Tyres
Tyre Size Front 90 / 90 x 19 - 52 P
Tyre Size Rear 110 / 90 x 17 - 60 P
Features
> Powerful 109cc engine > Digital Analog Combo Meter Console with Service Due Indicator
> Comfortable wide seat > Combined Braking System for simultaneous application of front and rear brakes
> Stylish rear grab rails > Multi-lever key with Magnetic head and shutter
> Maintenance free battery > Bold trapezoidal multi-focal reflector headlamp and striking front visor
> Viscous Paper Pleated Air Filter > Combination tail lamp and clear lens winkers
> Large storage space
