TECHNICAL SPECIFICATION

--------------------------------------------------------------------------------------------------

Engine

Type Air-cooled, 4-stroke single cylinder OHC

Displacement 97.2 cc

Max. Power 5.74 KW (7.8 Pc) @ 7500 rpm

Max. Torque 8.04 N-m @ 4500 RPM

Compression Ratio 9.0 : 1

Starting Kick start / Self start

Ingnition Digital CDI

Transmission & Chassis

Cluch Multi-plate wet

Gear box 4 Speed constant mesh

Chassis Type Tubular double cradle frame

Suspension

Front Telescopic hydraulic shock absorbers

Rear Swing arm with 5 step adjustable hydraulic shock absorber

Brakes

Front Brake Internal expanding shoe type (130 mm) type

Rear Brake Disc Internal expanding shoe type (130 mm) type

Wheels & Tyres

Rim Size Front 18 x 1.60, Spoke wheel / Cast wheel

Rim Size Rear 18 x 1.60, Spoke wheel / Cast wheel

Tyre Size Front 2.75 x 18 - 42 P / 4 PR, Unidirectional tyre

Tyre Size Rear 2.75 x 18 - 48 P / 6 PR, Unidirectional tyre

Electricals

Battery MF battery, 12V 3Ah (Kick), 12 V4 Ah (Self)

Head Light 12V 35W / 35W - Halogen bulb ( Multi - reflector

type )

Dimensions

Length 1970 mm

Width 720 mm

Height 1040 mm

Ground Clearance 159mm

Fuel Tank Capacity 11 ltrs (Min).

Kerb Weight 109 kg, (Kick), 112 kg (Self)
